| Part No. |
Frequency (MHz) |
FLASH(KB) | SRAM(KB) | SDRAM | FPU | I/Os | Vmin(V) | Vmax(V) | Timer |
Analog Interface |
Connectivity | Package | |||||||||||||||||||||
| GPTMR(16bit) | GPTMR(32bit) |
Advanced TMR(16bit) |
Basic TMR |
Systick (24bit) |
IWDG | WWDG | RTC |
ADC 12-bit Cell |
ADC 12-bit Channels |
DAC 12-bit Cell |
DAC 12-bit Channels |
Analog Comparator |
EMMC | SPI | I2S | I2C | U(S)ART | CAN | SDIO |
USB Device |
CEC |
USB OTG_FS |
Ethernet | ||||||||||
| APM32F103CCT6 | 96 | 256 | 64 | 0 | 0 | 37 | 2 | 3.6 | 4 | 0 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 10 | 2 | 2 | 0 | 0 | 3 | 2 | 2 | 3 | 2 | 0 | 1 | 0 | 0 | 0 | LQFP48 |
| APM32F103RCT6 | 96 | 256 | 64 | 0 | 0 | 51 | 2 | 3.6 | 4 | 0 | 2 | 2 | 1 | 1 | 1 | 1 | 3 | 16 | 2 | 2 | 0 | 0 | 3 | 2 | 2 | 3+2 | 2 | 1 | 1 | 0 | 0 | 0 | LQFP64 |
| APM32F103VCT6 | 96 | 256 | 64 | 0 | 0 | 80 | 2 | 3.6 | 4 | 0 | 2 | 2 | 1 | 1 | 1 | 1 | 3 | 16 | 2 | 2 | 0 | 1 | 3 | 2 | 2 | 3+2 | 2 | 1 | 1 | 0 | 0 | 0 | LQFP100 |
