| Part No. |
Frequency (MHz) |
FLASH(KB) | SRAM(KB) | SDRAM | FPU | I/Os | Vmin(V) | Vmax(V) |
GPTMR (16bit) |
GPTMR (32bit) |
Advanced TMR(16bit) |
Basic TMR |
Systick (24bit) |
IWDG | WWDG | RTC |
ADC 12-bit Cell |
ADC 12-bit channels |
DAC 12-bit Cell |
DAC 12-bit channels |
Analog Comparator |
EMMC | SPI | I2S | I2C | U(S)ART | CAN | SDIO |
USB Device |
CEC | Package |
| APM32F103RDT6 | 96 | 384 | 64 | 0 | 1 | 51 | 2 | 3.6 | 4 | 0 | 2 | 2 | 1 | 1 | 1 | 1 | 3 | 16 | 2 | 2 | 0 | 0 | 3 | 2 | 2 | 3+2 | 1 | 1 | 1 | 0 | LQFP64 |
| APM32F103RET6 | 96 | 512 | 128 | 0 | 1 | 51 | 2 | 3.6 | 4 | 0 | 2 | 2 | 1 | 1 | 1 | 1 | 3 | 16 | 2 | 2 | 0 | 0 | 3 | 2 | 2 | 3+2 | 1 | 1 | 1 | 0 | LQFP64 |
| APM32F103VDT6 | 96 | 384 | 64 | 0 | 1 | 80 | 2 | 3.6 | 4 | 0 | 2 | 2 | 1 | 1 | 1 | 1 | 3 | 16 | 2 | 2 | 0 | 1 | 3 | 2 | 2 | 3+2 | 1 | 1 | 1 | 0 | LQFP100 |
| APM32F103VET7 | 96 | 512 | 128 | 0 | 1 | 80 | 2 | 3.6 | 4 | 0 | 2 | 2 | 1 | 1 | 1 | 1 | 3 | 16 | 2 | 2 | 0 | 1 | 3 | 2 | 2 | 3+2 | 1 | 1 | 1 | 0 | LQFP100 |
| APM32F103VET6 | 96 | 512 | 128 | 0 | 1 | 80 | 2 | 3.6 | 4 | 0 | 2 | 2 | 1 | 1 | 1 | 1 | 3 | 16 | 2 | 2 | 0 | 1 | 3 | 2 | 2 | 3+2 | 1 | 1 | 1 | 0 | LQFP100 |
| APM32F103ZDT6 | 96 | 384 | 64 | 1 | 1 | 112 | 2 | 3.6 | 4 | 0 | 2 | 2 | 1 | 1 | 1 | 1 | 3 | 21 | 2 | 2 | 0 | 1 | 3 | 2 | 2 | 3+2 | 1 | 1 | 1 | 0 | LQFP144 |
| APM32F103ZET6 | 96 | 512 | 128 | 1 | 1 | 112 | 2 | 3.6 | 4 | 0 | 2 | 2 | 1 | 1 | 1 | 1 | 3 | 21 | 2 | 2 | 0 | 1 | 3 | 2 | 2 | 3+2 | 1 | 1 | 1 | 0 | LQFP144 |
